WE-TPC 2813 Series
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

744029004

Digi-Key Part Number
732-1089-2-ND - Tape & Reel (TR)
732-1089-1-ND - Cut Tape (CT)
732-1089-6-ND - Digi-Reel®
Manufacturer
Würth Elektronik
Manufacturer Product Number
744029004
Description
FIXED IND 4.7UH 1A 200 MOHM SMD
Manufacturer Standard Lead Time
11 Weeks
Detailed Description
4.7 µH Shielded Drum Core, Wirewound Inductor 1 A 200mOhm Max Nonstandard
Customer Reference
Datasheet
 Datasheet
EDA/CAD Models
744029004 Models
Product Attributes
Type
Description
Select All
Category
Mfr
Würth Elektronik
Series
WE-TPC
Package
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
Product Status
Active
Type
Drum Core, Wirewound
Material - Core
Ferrite
Inductance
4.7 µH
Tolerance
±30%
Current Rating (Amps)
1 A
Current - Saturation (Isat)
800mA
Shielding
Shielded
DC Resistance (DCR)
200mOhm Max
Q @ Freq
-
Frequency - Self Resonant
65MHz
Ratings
-
Operating Temperature
-40°C ~ 125°C
Inductance Frequency - Test
100 kHz
Mounting Type
Surface Mount
Package / Case
Nonstandard
Supplier Device Package
2828
Size / Dimension
0.110" L x 0.110" W (2.80mm x 2.80mm)
Height - Seated (Max)
0.059" (1.50mm)
Documents & Media
Resource TypeLink
Datasheets744029004
Video File
@AskLorandt explains: Rated current of an inductor
@askLorandt explains: LC-Input filter for DC-DC converter
@askLorandt explains: T-Input filter for DC/DC converter
WEbinar Powered by Digi-Key: Inductors (Portuguese)
WEbinar Powered by Digi-Key: Inductors – Basic Principles of Inductors
Environmental InformationRoHS Cert
Design Resources744029004 Red Expert Design Tool
Featured ProductTiny Power Inductors
CAD Models744029004 Models
PCN Design/Specification
PCN Packaging
PCN OtherMult Devices Label 22/Dec/2021
HTML Datasheet744029004
EDA Models744029004 Models
Product Drawings
Environmental & Export Classifications
AttributeDescription
RoHS StatusROHS3 Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
REACH StatusREACH Unaffected
ECCNEAR99
HTSUS8504.50.4000
Quantity
All prices are in JPY
Cut Tape (CT) & Digi-Reel®
QtyUnit PriceExt Price
1¥242.00000¥242
10¥234.30000¥2,343
50¥205.06000¥10,253
100¥193.35000¥19,335
500¥165.18200¥82,591
* All Digi-Reel orders will add a ¥800 reeling fee.
Tape & Reel (TR)
QtyUnit PriceExt Price
1,200¥133.38000¥160,056
2,400¥119.77375¥287,457
Manufacturers Standard Package
Kits
Related ProductsSee All 120
Additional Resources
AttributeDescription
Other Names
732-1089-1
732-1089-2
732-1089-6
Standard Package1,200
