Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
RCLAMP0542T.TCT | |
|---|---|
DigiKey Part Number | RCLAMP0542TTCTTR-ND - Tape & Reel (TR) RCLAMP0542TTCTCT-ND - Cut Tape (CT) RCLAMP0542TTCTDKR-ND - Digi-Reel® |
Manufacturer | |
Manufacturer Product Number | RCLAMP0542T.TCT |
Description | TVS DIODE 5VWM 15VC SLP1610P4T |
Manufacturer Standard Lead Time | 13 Weeks |
Customer Reference | |
Detailed Description | 15V Clamp 5A (8/20µs) Ipp Tvs Diode Surface Mount SLP1610P4T |
Datasheet | Datasheet |
EDA/CAD Models | RCLAMP0542T.TCT Models |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Part Status | Active | |
Type | Steering (Rail to Rail) | |
Unidirectional Channels | 2 | |
Voltage - Reverse Standoff (Typ) | 5V (Max) | |
Voltage - Breakdown (Min) | 6.5V | |
Voltage - Clamping (Max) @ Ipp | 15V | |
Current - Peak Pulse (10/1000µs) | 5A (8/20µs) | |
Power - Peak Pulse | 75W | |
Power Line Protection | Yes | |
Applications | Ethernet, HDMI | |
Capacitance @ Frequency | 0.45pF @ 1MHz | |
Operating Temperature | -55°C ~ 125°C (TJ) | |
Mounting Type | Surface Mount | |
Package / Case | 6-UFDFN | |
Supplier Device Package | ||
Base Product Number |
In-Stock: 28,843
Check for Additional Incoming Stock
Quantity
All prices are in JPY
Cut Tape (CT) & Digi-Reel®
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | ¥217.00000 | ¥217 |
| 10 | ¥136.30000 | ¥1,363 |
| 100 | ¥89.77000 | ¥8,977 |
| 500 | ¥69.74200 | ¥34,871 |
| 1,000 | ¥63.29400 | ¥63,294 |
Tape & Reel (TR)
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 3,000 | ¥55.10333 | ¥165,310 |
| 6,000 | ¥50.98017 | ¥305,881 |
| 9,000 | ¥48.88000 | ¥439,920 |
| 15,000 | ¥46.52033 | ¥697,805 |
| 21,000 | ¥45.12357 | ¥947,595 |
| 30,000 | ¥43.76657 | ¥1,312,997 |
| Unit Price without JCT: | ¥217.00000 |
|---|---|
| Unit Price with JCT: | ¥238.70000 |
