Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
ZXMN10A08E6TA | ||
|---|---|---|
Digi-Key Part Number | ZXMN10A08E6TR-ND - Tape & Reel (TR) ZXMN10A08E6CT-ND - Cut Tape (CT) ZXMN10A08E6DKR-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | ZXMN10A08E6TA | |
Description | MOSFET N-CH 100V 1.5A SOT26 | |
Manufacturer Standard Lead Time | 8 Weeks | |
Detailed Description | N-Channel 100 V 1.5A (Ta) 1.1W (Ta) Surface Mount SOT-26 | |
Customer Reference | ||
Datasheet | Datasheet | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | - | |
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
FET Type | ||
Technology | ||
Drain to Source Voltage (Vdss) | 100 V | |
Current - Continuous Drain (Id) @ 25°C | ||
Drive Voltage (Max Rds On, Min Rds On) | 6V, 10V | |
Rds On (Max) @ Id, Vgs | 250mOhm @ 3.2A, 10V | |
Vgs(th) (Max) @ Id | 4V @ 250µA | |
Gate Charge (Qg) (Max) @ Vgs | 7.7 nC @ 10 V | |
Vgs (Max) | ±20V | |
Input Capacitance (Ciss) (Max) @ Vds | 405 pF @ 50 V | |
FET Feature | - | |
Power Dissipation (Max) | 1.1W (Ta) | |
Operating Temperature | -55°C ~ 150°C (TJ) | |
Mounting Type | Surface Mount | |
Supplier Device Package | SOT-26 | |
Package / Case | ||
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | ZXMN10A08E6TC |
| Environmental Information | Diodes Environmental Compliance Cert |
| PCN Design/Specification | |
| PCN Assembly/Origin | Mult Dev A/T Site 31/Mar/2021 |
| PCN Other | Copper Bond Wire and Wafer Source 07/Nov/2013 |
| Product Drawings | SOT-23-6 Pin Out |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.29.0095 |
In-Stock: 34,550
Quantity
All prices are in JPY
Cut Tape (CT) & Digi-Reel®
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | ¥101.00000 | ¥101 |
| 10 | ¥86.70000 | ¥867 |
| 100 | ¥60.25000 | ¥6,025 |
| 500 | ¥47.04000 | ¥23,520 |
| 1,000 | ¥38.23300 | ¥38,233 |
Tape & Reel (TR)
| Qty | Unit Price | Ext Price |
|---|---|---|
| 3,000 | ¥34.17767 | ¥102,533 |
| 6,000 | ¥32.44000 | ¥194,640 |
| 9,000 | ¥30.12278 | ¥271,105 |
| 30,000 | ¥29.42770 | ¥882,831 |
Manufacturers Standard Package
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | ZXMN10A08E6CT-NDR Q3400736A ZXMN10A08E6TR ZXMN10A08E6TR-NDR ZXMN10A08E6CT ZXMN10A08E6DKR |
| Standard Package | 3,000 |
