Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
SMCJ5.0CA-13-F | ||
|---|---|---|
Digi-Key Part Number | SMCJ5.0CA-FDITR-ND - Tape & Reel (TR) SMCJ5.0CA-FDICT-ND - Cut Tape (CT) SMCJ5.0CA-FDIDKR-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | SMCJ5.0CA-13-F | |
Description | TVS DIODE 5VWM 9.2VC SMC | |
Manufacturer Standard Lead Time | 16 Weeks | |
Detailed Description | 9.2V Clamp 163A Ipp Tvs Diode Surface Mount SMC | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | SMCJ5.0CA-13-F Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | - | |
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
Type | Zener | |
Bidirectional Channels | 1 | |
Voltage - Reverse Standoff (Typ) | 5V | |
Voltage - Breakdown (Min) | 6.4V | |
Voltage - Clamping (Max) @ Ipp | 9.2V | |
Current - Peak Pulse (10/1000µs) | 163A | |
Power - Peak Pulse | 1500W (1.5kW) | |
Power Line Protection | No | |
Applications | General Purpose | |
Capacitance @ Frequency | - | |
Operating Temperature | -55°C ~ 150°C (TJ) | |
Mounting Type | Surface Mount | |
Package / Case | DO-214AB, SMC | |
Supplier Device Package | ||
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | SMCJ5.0(C)A - SMCJ170(C)A |
| Environmental Information | Diodes Environmental Compliance Cert |
| PCN Assembly/Origin | Assembly Site 01/Jun/2022 |
| EDA Models | SMCJ5.0CA-13-F Models |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.10.0080 |
Quantity
All prices are in JPY
Cut Tape (CT) & Digi-Reel®
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | ¥127.00000 | ¥127 |
| 10 | ¥109.00000 | ¥1,090 |
| 100 | ¥75.50000 | ¥7,550 |
| 500 | ¥63.09000 | ¥31,545 |
| 1,000 | ¥53.69400 | ¥53,694 |
Tape & Reel (TR)
| Qty | Unit Price | Ext Price |
|---|---|---|
| 3,000 | ¥47.82133 | ¥143,464 |
| 6,000 | ¥45.30417 | ¥271,825 |
| 9,000 | ¥41.94822 | ¥377,534 |
| 30,000 | ¥41.53300 | ¥1,245,990 |
Manufacturers Standard Package
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | SMCJ5.0CA-FDIDKR SMCJ5.0CA-FDICT SMCJ5.0CA-FDITR SMCJ5.0CA13F |
| Standard Package | 3,000 |
