MA00L1NZQD | ||
|---|---|---|
Digi-Key Part Number | CKN6045-ND | |
Manufacturer | ||
Manufacturer Product Number | MA00L1NZQD | |
Description | SWITCH ROTARY 10POS 250MA 125V | |
Manufacturer Standard Lead Time | 12 Weeks | |
Detailed Description | Rotary Switch 10 Position SP10T 250mA (AC/DC) 125 VAC Panel Mount | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | MA00L1NZQD Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | C&K | |
Series | ||
Package | Tray | |
Product Status | Active | |
Number of Positions | 10 | |
Index Stops | Continuous | |
Number of Decks | 1 | |
Number of Poles per Deck | 1 | |
Circuit per Deck | SP10T | |
Contact Timing | Non-Shorting (BBM) | |
Current Rating (Amps) | 250mA (AC/DC) | |
Voltage Rating - AC | 125 V | |
Voltage Rating - DC | 28 V | |
Actuator Type | Flatted (3.17mm Dia) | |
Actuator Length | 10.16mm | |
Angle of Throw | 36° | |
Contact Material | Copper Alloy | |
Contact Finish | Silver | |
Mounting Type | Panel Mount | |
Termination Style | Solder Lug | |
Features | - | |
Depth Behind Panel | 14.86mm | |
Panel Cutout Dimensions | Circular - 6.60mm Dia | |
Base Product Number |
