HMC753LP4E HEMT MMIC Low-Noise RF Amplifier

GaAs MMIC low-noise wideband amplifier housed in a leadless 4 mm x 4 mm plastic surface-mount package from Analog Devices

Image of Analog Devices HMC753LP4E HEMT MMIC Low Noise RF AmplifierThe ADI's HMC753LP4E is a GaAs MMIC low-noise wideband amplifier housed in a leadless 4 mm x 4 mm plastic surface-mount package. The amplifier operates between 1 and 11 GHz, providing up to 16.5 dB of small signal gain, 1.5 dB noise figure, and output IP3 of +30 dBm, while requiring only 55 mA from a +5 V supply. The P1dB output power of up to +18 dBm enables the LNA to function as an LO driver for balanced I/Q or image reject mixers. The HMC753LP4E also features I/Os that are DC blocked and internally matched to 50 Ω, making it ideal for high capacity microwave radios or VSAT applications. This versatile LNA is also available in die form as the HMC-ALH444.

Features
  • Noise figure: 1.5 dB at 4 GHz
  • Gain: 16.5 dB
  • P1dB output power: +18 dBm
  • Supply voltage: +5 V at 55 mA
  • Output IP3: +30 dBm
  • 50 Ω matched input/output
  • 24-lead plastic 4 mm x 4 mm SMT package: 16mm²

Evaluation Board

ImageManufacturer Part NumberDescriptionAvailable QuantityPriceView Details
BOARD EVAL AMP MMIC HMC753122826-HMC753LP4EBOARD EVAL AMP MMIC HMC7530 - Immediate$212,429.00View Details

HMC753LP4E HEMT MMIC Low-Noise RF Amplifier

ImageManufacturer Part NumberDescriptionAvailable QuantityPriceView Details
IC RF AMP GPS 1GHZ-11GHZ 24QFNHMC753LP4EIC RF AMP GPS 1GHZ-11GHZ 24QFN15 - Immediate$22,532.00View Details
IC RF AMP GPS 1GHZ-11GHZ 24QFNHMC753LP4ETRIC RF AMP GPS 1GHZ-11GHZ 24QFN260 - Immediate$22,532.00View Details
