1-1734592-2
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

1-1734592-2

Digi-Key Part Number
A100283TR-ND - Tape & Reel (TR)
A100283CT-ND - Cut Tape (CT)
A100283DKR-ND - Digi-Reel®
Manufacturer
TE Connectivity AMP Connectors
Manufacturer Product Number
1-1734592-2
Description
CONN FPC BOTTOM 12POS 0.5MM R/A
Manufacturer Standard Lead Time
23 Weeks
Detailed Description
12 Position FPC Connector Contacts, Bottom 0.020" (0.50mm) Surface Mount, Right Angle
Customer Reference
Datasheet
 Datasheet
EDA/CAD Models
1-1734592-2 Models
Product Attributes
Type
Description
Select All
Category
Mfr
TE Connectivity AMP Connectors
Series
-
Package
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
Product Status
Active
Flat Flex Type
FPC
Mounting Type
Surface Mount, Right Angle
Connector/Contact Type
Contacts, Bottom
Number of Positions
12
Pitch
0.020" (0.50mm)
Termination
Solder
FFC, FCB Thickness
0.30mm
Height Above Board
0.081" (2.05mm)
Locking Feature
Slide Lock
Cable End Type
Tapered
Contact Material
Phosphor Bronze
Contact Finish
Gold
Housing Material
Liquid Crystal Polymer (LCP)
Actuator Material
Thermoplastic
Features
Solder Retention, Zero Insertion Force (ZIF)
Voltage Rating
250V
Operating Temperature
-40°C ~ 85°C
Material Flammability Rating
UL94 V-0
Current Rating (Amps)
0.5A
Contact Finish Thickness
Flash
Housing Color
Natural
Actuator Color
Ivory
Mating Cycles
-
Base Product Number
1734592
Documents & Media
Resource TypeLink
Datasheets1-1734592-2
Video File
Flexible Printed Circuit Connectors FAQ
TE Connectivity FPC Overview
Environmental Information1-1734592-2 Statement of Compliance
Featured Product
PCN Design/SpecificationResin chg 21/FEB/2022
HTML Datasheet1734592 Drawing
EDA Models1-1734592-2 Models
3D Drawings1-1734592-2.pdf
Product Drawings
Environmental & Export Classifications
AttributeDescription
RoHS StatusROHS3 Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
REACH StatusVendor Undefined
ECCNEAR99
HTSUS8536.69.4040
Quantity
All prices are in JPY
Tape & Reel (TR)
QtyUnit PriceExt Price
2,000¥68.44150¥136,883
4,000¥64.76650¥259,066
6,000¥59.71383¥358,283
10,000¥56.84880¥568,488
Manufacturers Standard Package
Cut Tape (CT)
QtyUnit PriceExt Price
1¥112.00000¥112
10¥109.30000¥1,093
25¥108.84000¥2,721
50¥105.18000¥5,259
100¥88.19000¥8,819
250¥82.68000¥20,670
500¥78.08800¥39,044
1,000¥68.44200¥68,442
Digi-Reel®
QtyUnit PriceExt Price
1¥133.00000¥133
10¥112.50000¥1,125
25¥107.96000¥2,699
50¥105.66000¥5,283
100¥101.06000¥10,106
250¥91.86800¥22,967
500¥82.68000¥41,340
1,000¥73.49400¥73,494
* All Digi-Reel orders will add a ¥800 reeling fee.
You May Also Be Interested InSee All 30
Additional Resources
AttributeDescription
Other Names
-1-1734592-2-CSI
A100283TR
2266-1-1734592-2TR
A100283CT
117345922
A100283DKR
-1-1734592-2-SI
1-1734592-2-ND
Standard Package2,000
