ESE-13H01D | ||
---|---|---|
Digi-Key Part Number | P13359STR-ND - Tape & Reel (TR) P13359SCT-ND - Cut Tape (CT) P13359SDKR-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | ESE-13H01D | |
Description | SWITCH DETECTOR SPST-NO 10MA 5V | |
Manufacturer Standard Lead Time | 19 Weeks | |
Detailed Description | Switch SPST-NO Surface Mount, Right Angle | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | ESE-13H01D Models |
Type | Description | Select All |
---|---|---|
Category | ||
Mfr | Panasonic Electronic Components | |
Series | ||
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
Circuit | SPST-NO | |
Switch Function | Off-Mom | |
Current Rating (Amps) | 10mA (DC) | |
Voltage Rating - DC | 5 V | |
Actuator Type | Angled Toggle (Detector) | |
Mounting Type | Surface Mount, Right Angle | |
Termination Style | SMD (SMT) Tab | |
Ingress Protection | - | |
Features | Board Guide | |
Operating Force | 30gf | |
Release Force | - | |
Operating Position | 15° | |
Pretravel | 15° | |
Differential Travel | - | |
Overtravel | 60° | |
Operating Temperature | -10°C ~ 60°C | |
Electrical Life | 50,000 Cycles | |
Mechanical Life | 50,000 Cycles | |
Base Product Number |
Resource Type | Link |
---|---|
Datasheets | ESE-13 Series Datasheet |
CAD Models | ESE-13H01D Models |
PCN Packaging | |
Product Drawings |
Attribute | Description |
---|---|
RoHS Status | ROHS3 Compliant |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
REACH Status | REACH Unaffected |
ECCN | EAR99 |
HTSUS | 8536.50.7000 |
Qty | Unit Price | Ext Price |
---|---|---|
1 | ¥104.00000 | ¥104 |
10 | ¥99.20000 | ¥992 |
25 | ¥95.56000 | ¥2,389 |
100 | ¥82.72000 | ¥8,272 |
250 | ¥75.36000 | ¥18,840 |
500 | ¥69.84600 | ¥34,923 |
1,000 | ¥62.49300 | ¥62,493 |
2,500 | ¥59.18480 | ¥147,962 |
Qty | Unit Price | Ext Price |
---|---|---|
5,000 | ¥54.77340 | ¥273,867 |
10,000 | ¥51.09730 | ¥510,973 |
Attribute | Description |
---|---|
Other Names | P13359SCT ESE13H01D P13359STR P13359SDKR |
Standard Package | 5,000 |
